- New L-M Rails
- New Ball Screw
- Turret re-sleeved and Auto Index Rebuilt
- Automatic Repositioning – Heavy duty work holders secure material during repositioning.
- Precision ground re-circulating ball leads screws for X and Y Axis
- X and Y carriages driven by AC servo motors
- Crash proof clamp sensors
- Hardened and ground turret index pins and bushings
- Safety interlocks and overrun protectors with all step control prevent accidents
- 44 Station auto-index thick type turret for long body tools
- Strip miss
- Trap door
- Tool hoist
- RS 232 computer port
- Lights out scheduler
- Hydraulic/mechanical clutch and brake system
- 200 amp I.C. plasma unit original plasma unit
- Hyd. work clamps – thick material and thin
- Air blow available
- Optional High definition plasma available (Hypertherm HT)
Product Description
Features and Specs
| Manufacturer | Amada |
| Model | COMA 50-60-72 |
| Year | 1992 |
| Condition | Excellent |
| Location | Bensenville, IL |
| Capacity | 55 Ton |
| Max Sheet Size | 60" x 72" |
| Max Sheet Thickness | 1/2" M.S. |
| Axis Speed | 2000 IPM |
| Hit Speed 1" Gap | 200 |
| Nibbling Hits per Minute | 300 |
| Tooling Type | Thick Turret |
| Turret Rotation | 30 RPM |
| Tool Stations | 44 |
| Auto Index Stations | 2 |
| Machine Weight | 39,700 LBS |
| CNC Manufacturer | Fanuc |
| CNC Model | 04PC |
| Programming Modes | Absolute/Incremental |
| Programming Increment | .001" |
| Axis and Turret Drives | AC Servo Motors |
| Main Motor | 220/440v/60 cyl/3 ph. |
| Max Punch Diameter | 4.5 |
